Architectural Specifications

Support for Safer Facility Design with Entrapment Protection

Miller Edge products are designed for safe, code-compliant automation in new and existing construction projects. We offer a wide range of sensing and safety components to help architects and specifiers integrate entrapment protection into compliant commercial motorized door and automated vehicular gate from the start.

We work alongside design professionals to ensure the right safeguarding solutions are included in project specifications from the start.

Downloadable Product Specifications

Access specification documents formatted to industry standards. Our sensing safety products are listed across multiple architectural platforms and organized under applicable CSI divisions.

Doors, Hangar Doors, and Gates

Editable 3-part specifications written in CSI MasterFormat™ Division 08 structure for seamless integration into commercial and industrial project documents. Each file outlines performance requirements, UL 325 references, and submittal language for sensing edges, photo-optic sensors, and related accessories.

Documents are delivered in customizable Microsoft Word format and are suitable for direct use in Division 08 specifications for motorized doors and automated gates.

  • Section 08710 (08 78 03) – Door Safety Controls
    For motorized sectional and rolling doors
    Download DOCX
  • Section 08786 (08 78 06) – Hangar Door Safety Controls
    For large-scale, motor-driven hangar doors
    Download DOCX
  • Section 08789 (08 78 09) – Gate Safety Controls
    For automated vehicular gates
    Download DOCX

Highlights:

  • CSI-compliant 3-part format (General, Products, Execution)
  • Includes UL 325 references and submittal requirements
  • Fully editable in Microsoft Word for project customization

Doors, Gates, and Barriers

This manufacturer-specific 3-part specification is formatted to CSI MasterFormat™ Section 08 78 00 and created using Reed Construction Data’s MANU-SPEC® system. It is intended for direct use in project specs involving UL 325-compliant sensing solutions for commercial doors, vehicular gates, and access barriers.

The document includes detailed language for submittals, quality assurance, maintenance, and installation. Optional text and specifier notes are included for tailoring to project needs.

  • Section 08 78 00 – Door, Gate, and Barrier Controls
    Download PDF

Highlights:

  • Aligns with UL 325, NEC, NFPA, and ICC code references
  • Includes submittals, QA protocols, and maintenance guidance

Features editable sections and specifier notes for flexibility

Steel Sliding Hangar Doors

This federal specification is part of the Unified Facilities Guide Specifications (UFGS), issued by USACE, NAVFAC, and AFCESA for use in U.S. military and government construction. Section 08342 outlines mandatory use of fail-safe electric sensing edges on steel sliding hangar doors and details their required coverage, performance, and integration with the door control system.

The specification defines how sensing edges must respond to obstruction, interface with relay systems, and allow for keyed bypass reset and alert signaling. It supports low-voltage wiring (24V max) and calls for sealed, chemical-resistant construction.

  • Section 08342 – Steel Sliding Hangar Door Controls
    Download PDF

Highlights:

  • Applies to steel sliding hangar doors in federal and military projects
  • Includes wiring logic, keyed bypass, and obstruction alert requirements

Supports 24V relay-based integration with operator control systems

CAD & Specification Tools



CAD drawings, 3-part specs, and visual planning tools for design documentation.

Access CADdetails



Miller Edge products are available for direct use within the BSD SpecLink spec-writing platform.

Access RIB

Planning for Safety & Code Compliance

Our components help ensure compliance with relevant safety standards and reduce liability risks across automated entry systems.

Supported standards include:

  • UL 325 (U.S. and Canada)
  • ASTM F2200
  • Facility-specific guidelines and Authority Having Jurisdiction (AHJ) interpretations

For more information, visit our Standards & Codes resource page

Product Applications & Specification Support

Miller Edge manufactures a wide range of sensing solutions used in powered doors and gates. Products are available in multiple profiles, lengths, and configurations to match your project’s needs.

Let’s Simplify Specification Together

Whether you need help choosing a compatible product, understanding which format to use, or gathering documents for submittals, our team is here to help.

Ready to Move Your Project Forward?

Use the links above to download the files you need, or contact us for guidance. Miller Edge is your partner in integrating safety into every spec.
